TOYOTA Brake Caliper 47730-02110 47730-02111 4773002110 4773002111
Brake Caliper
The brake caliper plays a central role in a disc-brake system and has two functions. First, it acts either as a bracket to support the brake pads on either side of the rotor or to support the caliper bracket itself — there are other designs, but these are the two most common. Second, it uses pistons to convert pressure exerted on the brake fluid by the master cylinder into friction on the rotor.
Reference No.
| A.B.S. | 721342 |
| BUDWEG CALIPER | 343261 |
| TRW | BHQ306E/ BHQ306 |
| ATE | 24.3341-1704.5 |
| BOSCH | 0986135388 |
| Brake ENGINEERING | CA2286R |
Part List
| REPAIR KIT |
D42277C |
| PISTON |
233423 |
| REPAIR KIT |
203429 |
| GUIDE SLEEVE KIT |
169151 |
| SEAL, PISTON |
183429 |
Compatible Applications
| TOYOTA RUNX (ZZE12_, NDE12_, ZDE12_) (2001/11 – 2007/02) |
| TOYOTA COROLLA Saloon (_E12J_, _E12T_) (2001/03 – 2008/03) |
| TOYOTA COROLLA Est(_E12J_, _E12T_) (2001/12 – 2007/02) |
Assembling
1. Install the brake disc and brake pads if necessary.
2. Install the new brake caliper and tighten bolts to the specified torque.
3. Tighten the brake hose and then remove the pressure from the brake pedal
4. Make sure that all movable parts are lubricated and glide easily.
5. Re-connect the pad wear sensor wires if fitted.
6. Bleed the brake system by following the vehicle manufacturer’s guidelines.
7. Mount the wheels.
8. Tighten the wheel bolt/nuts with a torque wrench to the correct torque settings.
9. Check the brake fluid and replenish if necessary. Follow the operating instructions.
10. Check that there is no leakage of brake fluid.
11. Test the brakes on a brake test stand and carry out a test run.
